    Explore Doodle Labs’ diverse range of products, each tailored for specific use-cases and available in various frequency bands. Select a model to access comprehensive design-in documentation, including datasheets, hardware and software guides, schematics, regulatory information, and more.

    Mesh Rider® Radios



    Mesh Rider Radio models come in various form factors, each optimized for specific use-cases, enabling you to fully leverage the capabilities of our Mesh Rider OS in any system you develop.

    Mesh Rider Models
       nanoOEM-01a  miniOEM-01a mbOEM-01b palix-01b

    Unlicensed Frequency Bands
      Nano-OEM Mini-OEM OEM (V2) Wearable (V2)
    2.4-Ghz RM-2450-11N3
    RM-2450-11N4    		 RM-2450-12M3
    RM-2450-12M4
    900-MHz + 2.4-GHz
    		 RM-1700-21N3
    RM-1700-21N4    		 RM-1700-22M3
    RM-1700-22M4    		 RM-1700-22O3 RM-1700-22W3
    5-GHz     RM-5600-12O3 RM-5600-12W3

    Government Bands
    255 MHz + M3 + M4 + M6   RM--1300-42M3 RM--1300-42O3 RM--1300-42W3
    455 MHz + M3 + M4 + M6   RM--1400-42M3 RM--1400-42O3 RM--1400-42W3
    M1 - M6
    		 RM-2025-61N3
    RM-2025-61N4    		 RM-2025-62M3
    RM-2025-62M4    		 RM-2025-62O3 RM-2025-62W3
    L + S
    		 RM-2100-41N3
    RM-2100-41N4    		 RM-2100-42M3
    RM-2100-42M4    		 RM-2100-42O3 RM-2100-42W3
    Public Safety + ISM     RM-5400-22O3 RM-5400-22W3
    NATO-C + Federal + ISM     RM-5200-92O3 RM-5200-92W3

    Special
    Japan Robotics   RM-5700-2LSX-SA-ST   RM-5700-12W3

    Nimble Mesh Rider® Lite Wi-Fi Radios



    The Nimble Wi-Fi Radio enhances the legacy NM-DB Industrial Wi-Fi Transceivers by integrating Mesh Rider Lite (MRL) firmware. This Nimble Wi-Fi Radio upgrade boosts multi-band MANET capabilities, enables seamless integration with other Mesh Rider Radios, and incorporates Sense anti-jamming/interference avoidance technology.

    Nimble Wi-Fi Radios


    Wi-Fi 4 (IEEE 802.11n) + Mesh Rider Lite (MRL)
    2 x 2 MIMO Nimble-DB-2
    3 x 3 MIMO Nimble-DB-3

    Industrial Wi-Fi Transceivers



    For over fifteen years, we have supplied rugged Industrial Wi-Fi Transceivers to pioneers in some of the most regulated and leading-edge industries worldwide, such as robotics, aviation, industrial manufacturing, and defense applications.

    Industrial Wi-Fi Transceivers




    wifi-acn-ind-01

    		 11ax (black case) - hero 1

    Wi-Fi 5 (IEEE 802.11ac)
    2 x 2 MIMO ACM-DB-2
    3 x 3 MIMO ACM-DB-3

    Wi-Fi 6E (IEEE 802.11ax)
    2 x 2 MIMO   AX-TB6S-2-MM (Coming Soon)
    4 x 4 MIMO   AX-TB6S-4-MM
